Size Customized Industrial Structural Ceramics Excellent Mechanical and Thermal Properties

Name: Size Customized Industrial Structural Ceramics Excellent Mechanical and Thermal Properties
Brand: HENGYUAN
Price: 1 USD

Wholesale Size Customized Industrial Structural Ceramics Excellent Mechanical and Thermal Properties from china suppliers

Brand Name : HENGYUAN

Model Number : Structural Ceramics

Certification : CE,UL

Place of Origin : WUXI JIANGSU CHINA

MOQ : 100

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 5000 PCS/WEEK

Delivery Time : 20 DAYS

Packaging Details : Carton

Material : Structural Ceramics

Color : Yellow Or White

Usage : Industrial Ceramic

Size : Size Customized

OEM，ODM : Acceptable

Orgin : WUXI JIANGSU CHINA

MOQ : 100 PCS

Package : Package

Contact Now

Industrial Structural Ceramics Excellent Mechanical and Thermal Properties

Special ceramics as structural components. Composed of single or composite oxides or non oxides, such as Al2O3 alone ZrO2,SiC,Si3N4, Or they can be compounded with each other or combined with carbon fibers. Used for manufacturing ceramic engines and special components that are wear-resistant and high-temperature resistant.

Naterial	Unit	A95% Alumina Ceramics	A97% Alumina Ceramics	A99% Alumina Ceramics	A99.7% Alumina Ceramics
Density	g/cm³	3.6	3.72	3.85	3.85
Flexural Strength	Mpa	290	300	350	350
Compressive Strength	Mpa	3300	3400	3600	3600
Modulus of Elasticity	Gpa	340	350	380	380
Impact Resistance	MPam1/2	3.9	4	5	5
Weibull Modulus	M	10	10	11	11
Vickers Hardulus	HV0.5	1800	1850	1900	1900
Thermal Expansion Coefficient	10-6K-1	5.0-8.3	5.0-8.3	5.4-8.3	5.4-8.3
Thermal Conductivity	W/Mk	23	24	27	27
Thermal Shock Resistance	△T℃	250	250	270	270
*Maximum Use Temperature	℃	1600	1600	1650	1650
Volume Resistivity at 20℃	Ω	≥1014	≥1014	≥1014	≥1014
Dielectric Strength	KV/mm	20	20	25	25
Dielectric constant	εr	10	10	10	10
